Tecsun R-9012 radio

TECSUN R-9012 is a portable analog multiband receiver that can receive FM, Medium Wave (AM / MW) and Shortwave (SW) frequency bands.

This small low-cost shortwave receiver has analog tuning, allowing you to rotate a knob to search for known and yet unknown signals. It has a very basic design, but comes with a convenient tuning indicator light showing you when you are tuned into the signal, and a kickstand at the back of the cabinet, which allows for the radio to sit at a an angle for easy viewing of the display whilst listening.


Package Contents

• R-911 radio (Chinese version, please review provided photos)
• Carrying wrist strap
• English manual

Frequency Range

• FM: 76 - 108 MHz

• MW (AM): 525 - 1610 kHz

• SW: 3900 – 21850 kHz

  • SW1: 3900 - 4000 kHz
  • SW2: 4750 - 5060 kHz
  • SW3: 5950 - 6200 kHz
  • SW4: 7100 - 7300 kHz
  • SW5: 9500 - 9900 kHz
  • SW6: 11650 - 12050 kHz
  • SW7: 13600 - 13800 kHz
  • SW8: 15100 - 15600 kHz
  • SW9: 17550 - 17900 kHz
  • SW10: 21450 - 21850 kHz

Tuning Methods

• Jog dial manual Tuning

Basic Features

• Power ON/OFF switch
• Foldable kickstand
• LED tuning indicator
• Built-in speaker (0.5W)
• Earphone socket (3.5mm)
• DC jack (3V) (center negative polarity)

 Power

• Battery power:  2 x AA-size batteries
• DC power (for FM only): 3V (center negative polarity)

Unit Size

• 126 x 80 x 28 mm (L x H x W)

 Specifications


• Sensitivity
  • FM (S / N = 30dB) < 5µV
  • MW (S / N = 26dB) < 1mV/m
  • SW (S / N = 26dB) < 50µV
